A small team of Brazilian and Australian researchers have come up with a new way of fabricating optical fibre cable, which borrows some technology from modern 3D printers and could be both significantly faster and “at least 100 times cheaper” than existing methods.
Admittedly the price of optical fibre cable isn’t a particularly big issue for Fibre-to-the-Premises (FTTP) broadband ISPs, which are far more concerned about the much larger civil engineering and admin (wayleaves, planning etc.) costs of actually installing that cable into the ground or overhead. On the other hand, once you’re building hundreds or even thousands of kilometres of this stuff, even a small cost soon mounts up, so any extra saving is welcome.
The good news is that Professor Cristiano Cordeiro, of Brazil’s University of Campinas, has come up with a new simplified single-step fabrication process for Micro-structured Optical Fibre (MOF) cable that harnesses a low-cost off-the-shelf pellet-based filament extruder, which is about the size of a Microwave oven (existing approaches tend to require room-size machinery).
Essentially this device can make a variety of different fibre optic cables and is only limited by the number of pellets that are available to be fed into the extruder.
No preform fabrication is needed, meaning that drilling, capillary stacking, billet extrusion, or casting are “not necessary to make the preform for fibre drawing.”
Extract from Research Paper (Nature)
Our fiber fabrication procedure is time-efficient, and a MOF can be produced in less than 30 minutes. The process is also highly efficient in terms of electrical power and used floor-space, making straight-forward fabricating fibers in confined places and small laboratories with limited resources.
The produced fiber total length is no longer restricted by the preform or billet dimensions but just on how long the extruder can run continuously. As the pellets could potentially be fed to the extruder hopper continuously, the limitation is just related to how long the extruder could run uninterruptedly. At an average feeding rate (0.06 g/s), for example, one kilometer of 500 µm diameter fiber could be produced in an hour.
Apart from the virtually unlimited fiber length, the process is also versatile, allowing the quick production of a variety of different fiber geometries by merely changing the nozzle. The developed process opens the possibility to produce customized fibers on-demand, and with fast structural optimization to a specific target application.
3D printed titanium nozzles were used to fabricate three different types of specially designed MOFs. This demonstrates the flexibility of our new technique to manufacture different fiber designs.
The team’s current work only focused upon polymer optical fibres, although future plans for their research include the possibility to fabricate glass MOFs, following recent developments with 3D printing glassy materials. For a little context, here’s a short video on how existing glass preforms are turned into optical fibre (sadly we couldn’t find a more up-to-date video with modern systems):
